Photometric layouts
that prove the light.
Point-by-point AGi32 layouts that show the footcandles and uniformity before the order is placed, so the space comes in at the right level the first time.
From plans to a proven layout.
Plans + targets in
Send the drawings, the space types, and the light levels you need to hit. We confirm the mounting heights, surfaces, and code requirements before a single fixture goes on the plan.
Point-by-point calculation
We build the space in AGi32 and model the light, so footcandles, uniformity, and spill are numbers on a page, not a guess. You see exactly how the space performs before anything is ordered.
Fixture optimization
We tune the count, spacing, and optics to hit the target levels efficiently, so you are not paying for fixtures you do not need or fielding a callback for a space that came in dark.
Layout + schedule out
You get a clean layout drawing, a calculation summary, and a fixture schedule ready to quote and install, matched to the lines on the line card.
What we lay out
Interior, site, and specialty spaces, calculated and drawn to quote.
- Interior lighting layouts
- Site & parking lighting
- Sports & high-mast
- Footcandle & uniformity calcs
- Egress & code compliance
- Fixture count optimization
- AGi32 modeling
- Drawings & fixture schedules
Need a layout on a live job?
Send us the plans and the target levels and we will turn a photometric layout around for your bid or submittal.
